Technical feature

l  DMX512/1990 Standard 504 channels

l  LCD display with backlight up to 21 scanners may be connected with a maximum of 24 channels

l   Auto save last running data when power off or disconnect electric suddenly. Console will auto run continue while power ON or connect to electric

l   Set X,Y to light joystick of single fixture

l   8 slider for manual control of channels

l  LCD screen menu in Chinese/English

l  Up to 50 SHAPE generators. SHAPE track control is provided to control such effects as circles, lines and shapes like 8, etc

* Assignable joystick for ease of movement

* 24 chases run in circularly, Max 40 steps each chase

* Select one or multi chases to run in cycle

* Select multi chases to run at same time – SU, can run 8 chases simultaneously

* 960 chase steps

* Range of cross time: 0s-25.5s

* Range of speed time: 0.1s-25.5s

* Each chase speed and cross time can be saved automatic

* USB backup system enable user to backup the show in a file

* DMX signal output connector: XLR-D3F

* Power supply: AC88~256V 50/60Hz

* Dimension: 482mm×235mm×85mm

* Net Weight: 3.5Kg
