Technical Feature

 DMX512/1990 Standard

 24 channels switch output with Triac

 Switch output feature: DMX channel value

0-126=OFF, 127-255=ON

 Silicon bidirectional thyristors and zero-crossing

triggering

 LED indicators for each channel

 Over current protected with rapid fuse

 Channel output: 0.5A per channel, 12A total

 There are nine chase program inside and the

speed of these chase program can be selected

 DMX input connector: XLR-D3M

 DMX output connector: XLR-D3F

 Power supply: AC 88～256V 50/ 60Hz

 Dimension: 482mm×146mm×80mm

 Net Weight: 2.3kg
