Technical feature

* DMX512/1990 standard 512 DMX control channels.

* 4 output with separate optical isolated

* Up to 32 scanners may be connected with a maximum of 16 channels each.

* A large back light LCD to display operation parameters

* 16 channel faders plus 1 speed and 1 cross control the same time. And 32 scanners can be selected together

* The X/Y channels of different fixtures can be controlled by PAN/TILT wheel together

* 16 Bit control for PAN/TILT fine adjustment

* 15 environment programs to output the combination, which are composed of different scenes, chases and manual output quickly

*The music trigger source can be selected between audio line input or internal microphone

*Easy to learn and operate

*The Data auto-saves. (Through the electronic memory storage and it can be changed freely)

*High performance switching power supply, with extremely low power harmonious distortion and wide range of voltage, suit for the requirement of

different country simultaneously

*LED lamp connector

*Power input: DC9V 1000mA

* Dimension: 498mm × 420mm × 115mm

* Net Weight: 6.5kg

New Function

①   During program running, the program will run in preset speed when SPEED & CROSS faders at AUTO position otherwise the running speed will be total amount of current SPEED & CROSS faders.

②   When run Chase and environment program, press CROSS ode button to change CROSS mode between all channel mode or only X/Y mode.

③   After set PAN/TILT wheel, the faders and PAN/TILT wheel could control same channel value together (faders change channel value and PAN/TILT wheel fine adjust value).
